Print Precision

Short answer: An inkjet printhead fires drops measured in picoliters, trillionths of a liter. Home printers go down to about 1–1.5 pL, and some lab heads go below 1.

Thermal ('bubble jet') heads flash-boil a speck of ink so that a vapor bubble kicks a drop out. Piezo heads flex a crystal to squeeze it out. Drops fly at roughly 5–15 m/s, and Epson heads can fire up to 50,000 times a second. The best industrial heads land each drop within about a micron of its target.

VideoWrite-up7 sources

In collections:Engineering OdditiesEveryday Physics

More like this★ Support my pagesCite this file

What should you know about Print Precision?

Quick facts. Each one stands alone and has a stable ID you can cite.

  1. The smallest drops from modern inkjet printheads measure about 1–3 picoliters (trillionths of a liter).

    DD-005-F01 · Write-up · Exhibit B (Measured in trillionths of a liter)

  2. Inkjet drops typically leave the printhead at roughly 5–15 meters per second (about 14 m/s for HP's thermal heads).

    DD-005-F02 · Write-up · Exhibit E (Speed and frequency)

  3. Inkjet resolutions like 4800 × 1200 dpi describe the finest grid a printer can address, not the size of a single dot.

    DD-005-F03 · Write-up · Exhibit G (What '4800 dpi' means)

  4. Inkjet drops are measured in picoliters (trillionths of a liter). Home printers fire drops as small as about 1.3–1.5 pL.

    DD-005-F04 · Write-up · Exhibit B (Measured in trillionths of a liter)

  5. The best industrial inkjet heads land each drop within about ±1–2 microns of its target.

    DD-005-F05 · Write-up · Exhibit F (Within microns)

Video transcript: Print Precision: Your Printer Fires Drops a Trillionth of a Liter in Size

DID YOU KNOW? Inkjet printing precision comes from the ability to control and place microscopic droplets of ink with extreme accuracy, often measured in picoliters and positioned within microns of their intended location. Printheads use thermal or piezoelectric actuators to eject droplets at high speeds. NOW YOU KNOW!

Burned-in captions, read frame by frame (see transcript.md) · 16.5s Reel ·

Video coming soonPrint Precision · Instagram Reel
Print Precision: Your Printer Fires Drops a Trillionth of a Liter in Size Instagram Reel · · 16.5s

The write-up

Your printer fires drops a trillionth of a liter in size. Inkjet heads place picoliter droplets within microns, thousands of times a second.

  1. Exhibit A

    Two ways to fire a drop

    Thermal (bubble-jet) heads use a heater to make a vapor bubble that pushes ink out of the nozzle. Piezo heads apply a voltage to a piezoelectric element, which flexes and squeezes the drop out.

  2. Exhibit B

    Measured in trillionths of a liter

    Epson's piezo heads can deposit drops as small as 1.5 picoliters, one-and-a-half trillionths of a liter. HP's low-cost thermal cartridges fire 1.3 pL and 4.7 pL drops from nozzles 8.5 and 14 µm wide.

  3. Exhibit C

    Even smaller in the lab

    Canon's FINE research head ejected drops as small as 0.1 pL from a 2-micron orifice. Industrial heads like the Xaar 1003 AMp jet 1–3 pL sub-drops.

  4. Exhibit D

    A microsecond boil

    In an HP head, a 2.5-microsecond pulse heats a tiny resistor past the superheat point of water. That makes an almost explosive vapor bubble that launches the drop at about 50 km/h (14 m/s).

  5. Exhibit E

    Speed and frequency

    Drop speeds are typically about 5–15 m/s: about 14 m/s for HP's thermal drops, 7 m/s for the Xaar 1003, and 8–12 m/s for Canon's sub-picoliter drops. Epson heads can fire up to 50,000 drops per second.

  6. Exhibit F

    Within microns

    Placement is where the precision shows. A 1 pL head built for printing OLED displays achieved ±1.35 µm landing repeatability. Canon sped up its drops by 1.5 times so that air currents from the moving head push them off target less.

  7. Exhibit G

    What '4800 dpi' means

    Consumer printers advertise figures like 4800 × 1200 dpi. That's the finest grid the printer can address in its best mode, often combining two drop sizes. It isn't the size of a single dot.

Questions people ask about Print Precision

What are the two main ways inkjet printheads eject ink?

Thermal heads boil ink into a bubble; piezo heads flex a crystal to squeeze it out.

Source: Write-up · Exhibit A (Two ways to fire a drop) · Inkjet Printers: thermal and piezo ejection; FINE heads (Canon Global); Micro Piezo Inkjet Technology (Epson)

How small can Epson's Micro Piezo inkjet drops be?

As small as 1.5 picoliters, one-and-a-half trillionths of a liter.

Source: Write-up · Exhibit B (Measured in trillionths of a liter) · Micro Piezo Inkjet Technology (Epson); HP optimizes low-cost processing for inkjet printheads (Semiconductor Digest, 2008); HP offers new ink cartridge technology: 1.3 pL drops, up to 4800×1200 dpi (Philstar, 2008)

In a thermal inkjet head, what actually launches the drop?

A microsecond pulse superheats a resistor, and the vapor bubble kicks the drop out at about 50 km/h.

Source: Write-up · Exhibit D (A microsecond boil) · HP optimizes low-cost processing for inkjet printheads (Semiconductor Digest, 2008)

Roughly how fast do inkjet drops fly?

Sourced values range from about 7 to 14 m/s.

Source: Write-up · Exhibit E (Speed and frequency) · HP optimizes low-cost processing for inkjet printheads (Semiconductor Digest, 2008); Xaar 1003 AMp printhead specifications (Xaar); FINE-Printhead for Sub-picoliter Droplet (Canon; NIP/Digital Fabrication 2007); Micro Piezo Inkjet Technology (Epson)

What does a printer's '4800 × 1200 dpi' figure describe?

It's the addressable resolution in the best mode, not a single dot size.

Source: Write-up · Exhibit G (What '4800 dpi' means) · HP offers new ink cartridge technology: 1.3 pL drops, up to 4800×1200 dpi (Philstar, 2008); Inkjet Printers: thermal and piezo ejection; FINE heads (Canon Global)
