Offshore Oil

Short answer: Offshore oil and gas uses two kinds of structures. Fixed platforms are steel jackets pinned to the seabed with piles, compliant towers, and similar designs that sit over a field for decades.

Mobile offshore drilling units (MODUs) move from well to well. Jack-ups stand on legs lowered to the seabed in water up to about 450 ft. Semi-submersibles float on flooded pontoons and are held by anchors or thrusters, and drillships work in 2,000–10,000 ft of water using dynamic positioning. The Reel's own footage shows red-hulled jack-ups bridged to production platforms, a type it never names.

VideoWrite-up5 sources

In collections:Power and Energy

More like this★ Support my pagesCite this file

What should you know about Offshore Oil?

Quick facts. Each one stands alone and has a stable ID you can cite.

  1. Jack-up rigs lower their legs to the seafloor and lift their entire hull out of the water to drill, in seas up to about 450 ft deep.

    DD-033-F01 · Write-up · Exhibit C (Jack-ups: rigs on legs)

  2. Modern drillships hold position over a well in up to 10,000 ft of water with computer-controlled thrusters instead of anchors.

    DD-033-F02 · Write-up · Exhibit E (Drillships)

Video transcript: Offshore Oil: Some Oil Rigs Stand on Legs, Others Float

DID YOU KNOW? Oil rigs are large industrial structures used to drill for and extract petroleum and natural gas from beneath the Earth's surface, often in challenging environments like deep oceans or remote land areas. Offshore rigs range from fixed platforms anchored to the seabed, to floating systems like semi-submersibles and drill ships, that can operate in deep water while maintaining position with anchors or dynamic positioning systems. NOW YOU KNOW!

Burned-in captions, read frame by frame (see transcript.md) · 22.8s Reel ·

Video coming soonOffshore Oil · Instagram Reel
Offshore Oil: Some Oil Rigs Stand on Legs, Others Float Instagram Reel · · 22.8s

The write-up

Some oil rigs stand on legs, others float. Jack-ups, fixed platforms, semi-submersibles and drillships.

  1. Exhibit A

    Rigs vs. platforms

    Offshore drilling uses either a rig on a production platform or a mobile offshore drilling unit (MODU). MODUs fall into two groups: bottom-supported units (jack-ups, barges) and floating units (semi-submersibles and drillships).

  2. Exhibit B

    Fixed platforms

    Conventional fixed platforms sit on steel jackets secured into the seabed with steel piles. They're very sturdy but too costly beyond about 1,500 ft of water. Compliant towers flex with the sea and reach 1,500–3,000 ft.

  3. Exhibit C

    Jack-ups: rigs on legs

    A jack-up is towed to the site with its legs raised, then lowers them to the seafloor and lifts its hull clear of the water. It's the standard shallow-water rig, used in depths up to about 450 ft.

  4. Exhibit D

    Semi-submersibles

    Semis float on pontoons that are partly flooded to sit low and stable in the water. They're held in place by anchors, by thrusters (dynamic positioning) or both, and they're used extensively in rough waters like the North Sea.

  5. Exhibit E

    Drillships

    Drillships are ship-shaped rigs that drill through a moon pool in the hull. Modern ones use dynamic positioning, with computer-controlled thrusters, to hold position in 2,000–10,000 ft of water.

  6. Exhibit F

    Bridged complexes

    Many fields link several platforms with walkways that carry people and utilities between them. The Reel's footage shows jack-ups and production platforms joined this way.

Questions people ask about Offshore Oil

What kind of rig lowers its legs to the seafloor and lifts its hull out of the water?

A jack-up stands on legs in shallow water, up to about 450 ft.

Source: Write-up · Exhibit C (Jack-ups: rigs on legs) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Selected list of specialized words and their definitions (BSEE glossary); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE)

What keeps a conventional fixed platform in place?

Its steel jacket is secured into the seabed with piles.

Source: Write-up · Exhibit B (Fixed platforms) · Types of Fixed OCS Facilities (U.S. Coast Guard OCS National Center of Expertise)

What is 'dynamic positioning'?

Thrusters rotate and push to keep the rig over the well without anchors.

Source: Write-up · Exhibit E (Drillships) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE); Deepwater Development (BOEM/MMS, 2000)

Roughly how deep can modern drillships work?

Drillships handle deep and ultra-deep water, up to about 10,000 ft.

Source: Write-up · Exhibit E (Drillships) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE); Deepwater Development (BOEM/MMS, 2000)

How do semi-submersibles stay stable in rough seas?

Partly flooding the pontoons lowers them, making semis more stable than drillships.

Source: Write-up · Exhibit D (Semi-submersibles) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Selected list of specialized words and their definitions (BSEE glossary); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE)

Test Your Knowledge

All quizzes →

5 questions, all from this case file. Answers are revealed instantly.

  1. What kind of rig lowers its legs to the seafloor and lifts its hull out of the water?

    1. Drillship
    2. Jack-up
    3. Semi-submersible
    4. Tension-leg platform
    Show the answer

    Answer: B. Jack-up A jack-up stands on legs in shallow water, up to about 450 ft. Source: Write-up · Exhibit C (Jack-ups: rigs on legs) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Selected list of specialized words and their definitions (BSEE glossary); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE)

  2. What keeps a conventional fixed platform in place?

    1. Anchors
    2. Thrusters
    3. Steel piles driven into the seabed
    4. Its own weight on sand
    Show the answer

    Answer: C. Steel piles driven into the seabed Its steel jacket is secured into the seabed with piles. Source: Write-up · Exhibit B (Fixed platforms) · Types of Fixed OCS Facilities (U.S. Coast Guard OCS National Center of Expertise)

  3. What is 'dynamic positioning'?

    1. Moving rigs by tugboat
    2. Computer-controlled thrusters holding a vessel in place
    3. Raising legs
    4. Pumping ballast to sink
    Show the answer

    Answer: B. Computer-controlled thrusters holding a vessel in place Thrusters rotate and push to keep the rig over the well without anchors. Source: Write-up · Exhibit E (Drillships) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE); Deepwater Development (BOEM/MMS, 2000)

  4. Roughly how deep can modern drillships work?

    1. Up to 100 ft
    2. Up to 450 ft
    3. Up to 1,500 ft
    4. 2,000 to 10,000 ft
    Show the answer

    Answer: D. 2,000 to 10,000 ft Drillships handle deep and ultra-deep water, up to about 10,000 ft. Source: Write-up · Exhibit E (Drillships) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE); Deepwater Development (BOEM/MMS, 2000)

  5. How do semi-submersibles stay stable in rough seas?

    1. They rest on the seabed
    2. Flooded pontoons sit them low in the water
    3. Giant gyroscopes
    4. They're towed constantly
    Show the answer

    Answer: B. Flooded pontoons sit them low in the water Partly flooding the pontoons lowers them, making semis more stable than drillships. Source: Write-up · Exhibit D (Semi-submersibles) · Types of MODUs (U.S. Coast Guard OCS National Center of Expertise); Selected list of specialized words and their definitions (BSEE glossary); Subsea Drilling, Well Operations and Completions (National Petroleum Council paper 2-11, via DOE)
