Anatomy of a Combustion Engine

Short answer: In a four-stroke internal combustion engine, a piston draws in fuel and air, compresses it, and in gasoline engines a spark plug ignites it; diesel engines ignite the mixture by compression alone.

The expanding gas pushes the piston down, turning the crankshaft, and the exhaust stroke clears the cylinder. The footage shows cutaway views of an engine and ignition in slow motion.

VideoWrite-up2 sources
More like this★ Support my pagesCite this file

What should you know about Anatomy of a Combustion Engine?

Quick facts. Each one stands alone and has a stable ID you can cite.

  1. Intake, compression, power, exhaust.

    DD-334-F01 · Write-up · Exhibit A (Four strokes)

  2. Gasoline engines use spark plugs.

    DD-334-F02 · Write-up · Exhibit B (Spark)

Video transcript: Anatomy of a Combustion Engine: A Car Engine Runs on Thousands of Tiny Explosions a Minute

Did you know, combustion engines work by burning fuel to produce mechanical energy. Inside the engine, a mixture of fuel and air is compressed in a cylinder. A spark plug ignites the mixture, causing a small explosion, which pushes the piston down. This movement turns the crankshaft, converting the energy from the explosion into rotational force. The process repeats rapidly, producing the power that drives the vehicle. Combustion engines typically run on gasoline or diesel, and rely on a cycle of intake, compression, combustion, and exhaust to keep functioning. NOW YOU KNOW!

Burned-in captions, read frame by frame (see transcript.md) · 27.1s Reel ·

Video coming soonAnatomy of a Combustion Engine · Instagram Reel
Anatomy of a Combustion Engine: A Car Engine Runs on Thousands of Tiny Explosions a Minute Instagram Reel · · 27.1s

The write-up

A car engine runs on thousands of tiny explosions a minute. The four-stroke cycle turns them into rotation.

  1. Exhibit A

    Four strokes

    Intake, compression, power, exhaust.

  2. Exhibit B

    Spark

    Gasoline engines use spark plugs.

  3. Exhibit C

    Diesel

    Diesels ignite by compression.

  4. Exhibit D

    Piston

    Gas pushes the piston.

  5. Exhibit E

    Crankshaft

    The crankshaft turns.
